Rockwell Faceplate for Storefront Mortise Locks – Deadbolt, Hook Bolt & Deadlatch (FP1–FP15)

Faceplates for Rockwell storefront mortise locks: deadbolts, hook bolts and deadlatches. Pick the lock type, the profile that matches the edge of your door stile, and the finish. Each faceplate is 1″ wide × 6-7/8″ long (25.4 × 174.6 mm). Faceplates are ordered separately from the lock body, so one lock can be fitted to flat, beveled or radius stiles.

• Size: 1″ × 6-7/8″ (25.4 × 174.6 mm)
• Profiles: Flat, L.H. bevel, R.H. bevel, radius, radius with weatherstrip
• Finishes: Aluminum (AL) or bronze (DU)
• Part numbers: FP1–FP5 deadbolt, FP6–FP10 hook bolt, FP11–FP15 deadlatch

Which profile do I need? Look at the edge of the door stile where the lock goes. A square edge takes a flat faceplate. An angled edge takes a bevel faceplate, left or right hand to match the door. A rounded edge takes a radius faceplate, and a rounded edge with a weatherstrip channel takes the radius with weatherstrip.

Matching locks: hook bolt in stainless steel (31/32″, 1-1/8″, 1-1/2″) or steel (1-1/8″, 1-1/2″); deadbolt (31/32″, 1-1/8″); deadlatch (31/32″, 1-1/8″).
